您的位置: 首頁>>產品中心>>美國UVP
  • 美國uvp筆式紫外線燈電源
  • 美國uvp筆式紫外線燈電源

美國uvp筆式紫外線燈電源

Pen-Ray Lamps operate on AC current. For certain systems it may be desirable to operate the lamp at higher frequencies than 60 Hz. Lamps can operate satisfactorily at frequencies from 50 Hz to 50 kHz. Lamps using PS-6 operate at the nominal frequency of 38 kHz. Mating recommendations are available to provide optimum energy output from, and maximum life span of, Pen-Ray Lamps.

在線咨詢 價格咨詢
13818683556
美國uvp筆式紫外線燈電源產品詳情

UVP Pen-Ray Lamps Power Supplies

Pen-Ray Lamps operate on AC current. For certain systems it may be desirable to operate the lamp at higher frequencies than 60 Hz. Lamps can operate satisfactorily at frequencies from 50 Hz to 50 kHz. Lamps using PS-6 operate at the nominal frequency of 38 kHz. Mating recommendations are available to provide optimum energy output from, and maximum life span of, Pen-Ray Lamps.

The power supplies feature a standard lamp current shown in the chart. Power supplies can be ordered with specific ranges and currents. Contact Analytik Jena US for information.

Specific DC power supplies are designed as open power sources with board only and no housing for placement in other units.

Order Information


AC input power supplies

Part NumberModelInput CurrentPrimary VoltageLamp Current (mA/AC)Dimensions
         L x W x H (mm)
99-0055-01PS-1AC115V/60Hz18160 x 94 x 53
99-0055-02PS-1AC230V/50Hz18160 x 94 x 53
99-0056-01PS-2AC115V/60Hz6160 x 94 x 53
99-0056-02PS-2AC230V/50Hz6160 x 94 x 53
99-0057-01PS-3AC115V/60Hz10160 x 94 x 53
99-0057-02PS-3AC230V/50Hz10160 x 94 x 53
99-0004-01PS-4AC115V/60Hz26117 x 147 x 97
99-0004-02PS-4AC230V/50Hz26117 x 147 x 97
40-0062-01PS-8AC115V/60Hz30256 x 102 x 86
40-0062-02PS-8AC230V/50Hz30256 x 102 x 86
99-0033-01PS-9AC115V/60Hz48147 x 117 x 92
99-0033-02PS-9AC230V/50Hz48147 x 117 x 92

 DC input power supplies

Part NumberModelInput CurrentPrimary VoltageLamp Current (mA/AC)Dimensions
     L x W x H (mm)
44-0002-01PS-7*DC12V/30kHz5/1028 x 56 x 17
99-0076-01PS-6*DC24V/38kHz1898 x 89 x 38
99-0077-01PS-5*DC12V/38kHz1898 x 89 x 38
99-0065-01PS-6DC24V/38kHz28122 x 108 x 51
99-0065-02PS-6**DC24V/38kHz18122 x 108 x 51
99-0065-03PS-6DC24V/38kHz18122 x 108 x 51
99-0065-04PS-6**DC24V/38kHz10122 x 108 x 51
99-0065-05PS-6DC24V/38kHz10122 x 108 x 51
99-0065-06PS-6**DC24V/38kHz6122 x 108 x 51
99-0065-07PS-6DC24V/38kHz6122 x 108 x 51

* Board only
 ** With timer
